ZEBEX 独自のデュアルレーザー エンジンと他にはない Z-SCAN+ ハードウェア デコーディング技術を搭載した Z-6182 は、無敵のデコーディング速度と精度を保証します。大型スーパーマーケット、倉庫管理、生産プロセス管理などの大量処理用途に最適のツールです。
• アグレッシブなスキャン性能
• 即時の「オブジェクト接近通過」自動ウェイクアップ
• ビープ音と音量調節用のタッチ制御センサー
| Light Source | ||
|---|---|---|
| Dual 650 nm visible laser diodes (VLD) | ||
| Depth of Field | ||
| Z-6182GT 5 mil: 0 – 55 mm 7.5 mil: 0 – 120 mm 10 mil: 0 – 170 mm 13 mil: 0 – 200 mm 20 mil: 0 – 280 mm Z-6182 (with EAS) 5 mil: 0 – 55 mm 7.5 mil: 0 – 150 mm 10 mil: 0 – 200 mm 13 mil: 0 – 240 mm 20 mil: 0 – 320 mm Note: DOF may vary depending on environment condition and barcode quality. |
||
| Scan Lines | ||
| 40 | ||
| Scan Pattern | ||
| 10 directions of scan field | ||
| Scan Rate | ||
| 3,600 scans per second | ||
| Print Contrast | ||
| 45% @ UPC/EAN 100% | ||
| Indicator | ||
| Two-color LED (blue, red) | ||
| Programmable Operation | ||
| Programmable tone & beep time | ||
| System Interface | ||
| Keyboard, RS-232, HID USB, USB Virtual COM, OPOS , JPOS | ||
| Dimensions H x W x L | ||
|---|---|---|
| 152.5 × 152.0 × 82.0 mm | ||
| Weight (g) | ||
| 685 g (without cable) | ||
| Cable | ||
| Standard 2M straight | ||
| Input Voltage | ||
|---|---|---|
| 9 VDC ±10% | ||
| Power Consumption | ||
| 4.05 watts | ||
| Operating Current | ||
| 440 mA @ 9V ( Typical ) | ||
| Laser Class | ||
|---|---|---|
| CDRH Class IIa; IEC 60825 Class 1 | ||
| EMC | ||
| CE EN55022 B, FCC Part 15 Class B, VCCI, BSMI | ||
| Operating Temperature | ||
|---|---|---|
| 0° C to 40° C (32°F – 104°F) | ||
| Storage Temperature | ||
| -20°C to 60°C (-4°F – 140°F) | ||
| Humidity | ||
| 5% ~ 90% RH (no dewing allowed) | ||
| Light Level | ||
| Up to 4, 500 Lux (fluorescence) | ||
| Drop Durability | ||
| Designed to withstand 1M drops | ||
| 1D Barcode | ||
|---|---|---|
| UPC/EAN/JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39, Codabar, Code 128 & EAN 128, Code 93, ITF 2 of 5, IATA Code, MSI, China Postal Code, Code 32, Industrial 2 of 5, Standard 2 of 5, JAP, Code 11, GS1 DataBar, GS1 DataBar Limited, GS1 DataBar Expanded | ||
