Z-3272 Plus 為一維和二維條碼提供超快的掃描速度，讓您可以在不犧牲掃描質量或性能的情況下容納二維條碼。用戶無需花時間將條碼與掃描儀對齊或在掃描之間暫停。 每次掃描都獲得行業領先的掃描速度；真正的簡單掃描日常。 甚至損壞和印刷質量差的條碼都可輕易讀取；經久耐用的設計可確保全天的日常可靠性。
• 高速、全方位讀取一維、二維和郵政條碼
• 手動或自動觸發
• 從手機屏幕上可靠地讀取條碼
• 極低的耗電力
• 兩種佈線選項：USB 或 RS-232
• 耐用的包覆成型外殼和固定電纜確保跌落/衝擊耐受性
• 醫療保健標籤合規性：支持 GS1 和 FMD 格式
• IP42 防潮防塵
| Aiming Element | ||
|---|---|---|
| 617nm visible LED | ||
| Illumination Element | ||
| 617nm visible LED | ||
| Optical System | ||
| CMOS | ||
| Image Sensor | ||
| 1280 x 800 | ||
| Depth of Field | ||
| Code 39 (3 mil): 50 - 80 mm, Code 39 (5 mil): 50 - 150 mm, UPC/EAN (13 mil): 30 - 280 mm | ||
| Min. Bar Width | ||
| 3 mil (Code39) | ||
| Scan Angle | ||
| 38.6° horizontal; 24.9° vertical | ||
| Print Contrast | ||
| 30% @ UPC/EAN 100% | ||
| Indicator | ||
| Two-color LED (blue, red) | ||
| Programmable Operation | ||
| Scan mode, Beeper tone | ||
| System Interface | ||
| RS-232, USB | ||
| Dimensions H x W x L | ||
|---|---|---|
| 180.0 × 70.0 × 107.0 mm (device only) | ||
| Weight (g) | ||
| 150 g | ||
| Cable | ||
| Standard 2M straight | ||
| Input Voltage | ||
|---|---|---|
| 5 VDC ±10% | ||
| Operating Current | ||
| 230 mA @ 5V ( Typical ) | ||
| EMC | ||
|---|---|---|
| CE & FCC DOC compliant; VCCI; BSMI | ||
| Safety | ||
| IEC 62471 Exempt | ||
| Operating Temperature | ||
|---|---|---|
| 0°C – 50°C (32°F – 122°F) | ||
| Storage Temperature | ||
| -20°C – 60°C (-4°F – 140°F) | ||
| Humidity | ||
| 5% – 95% RH (non-condensing) | ||
| Light Level | ||
| 0 - 100,000 Lux ( fluorescence ) | ||
| Drop Durability | ||
| Designed to withstand 1.5M drops | ||
| Environmental Sealing | ||
| IP42 | ||
| 1D Barcode | ||
|---|---|---|
| UPC/EAN [UPCA/UPCE/ EAN-8/ EAN-13, ISBN (Bookland),ISSN], Code 39 (Standard, Full ASCII, Trioptic, Code 32 (ItalianPharmacode), Code 128, Code 93, Codabar, 2 of 5 (Interleaved2 of 5, Discrete 2 of 5, IATA, Chinese 2 of 5, Matrix 2 of 5, Code11), MSI Plessey, GS1 DataBar (Omnidirectional, Truncated,Stacked, Stacked Omnidirectional, Limited, Expanded, Expanded Stacked) | ||
| 2D Barcode | ||
| PDF417, MicroPDF417, Composite Codes(CC-A, CC-B, CC-C) , Aztec (Standard, Inverse),Maxicode, Data Matrix/ ECC 200 (Standard, Inverse), QR Code(Standard, Inverse, Micro) | ||
